LCD Size | 3.5" TFT LCD (Sunlight Readable) |
Brightness (cd/m2) | 190 cd/㎡ |
Max Resolution | 240 x 320 pixels QVGA |
Touch Screen | 4-Wire Resistive Type Touch |
Viewing Angle | 80/80/80/80 Deg. |
System | |
CPU | Marvell® PXA 310 624MHz |
Operating System | Microsof® Windows® Mobile 6.5 |
Memory | 128MB Flash + 256MB SDRAM |
Storage | MicroSD Slot |
Communication | |
Wireless LAN | WiFi 802.11 b/g |
Bluetooth | Bluetooth® 2.1 + EDR |
3.5G | WCDMA/HSDPA |
GPS | GPS w/internal antenna |
Data Collection | |
Barcode | 1D Laser Scan Engine |
Camera | 3 Megapixel CMOS Camera with LED Flash Light |
Indicator & Buttons | |
LED Indicator | Charging/Barcode status LED HSDPA status LED |
Hot Keys | 2 x Barcode Trigger |
I/O Interface | |
Audio | 1 x Headset |
Expansion | 16-Pin connector (RS232 / battery charging/ OTG-Host/ OTG-Client) 2'' Thermal Printer Smart Card Reader Support Magnetic Stripe Reader Support |
Power | |
Power Adapter | Input:VAC:90V~264V Output:12V/3A |
Battery | 7.4V 1,880 mAh battery |
Environment | |
Operating Temperature | 0ºC to 50ºC |
Storage Temperature | -20ºC to 70ºC |
Humidity | 5%~95% non-condensing |
Drop Survival | 1.2 M |
Environmental Protection | IP 54 (Excluding MSR/SCR/Printer) |
Certification | CE/FCC |
Physical Characteristics | |
Dimensions (LxWxH) (mm) | 230 x 84 x 54 |
Weight | 546 g |
