Display | |
LCD Size | 8.0" TFT LCD |
Brightness (cd/㎡) | 350 |
Max Resolution | 800 x 600 pixels SVGA |
Viewing Angle | 70/70/60/70 Deg. |
System | |
CPU | Intel®Atom™ Z530 1.6GHZ |
Chipset | Intel® SCH US15WP |
Operating System | Microsoft® Windows® XP Embedded |
Memory | 2G DDR2 SDRAM 533MHz On-Board |
Storage | CompactFlash® slot SD card slot |
Communication | |
Wireless LAN | Wi-Fi® 802.11b/g/n |
Bluetooth | Bluetooth® V3.0 + HS (Class II) |
Modem | WCDMA/HSUPA (Optional) |
Data Collection | |
Camera | 1.3 Megapixels |
Barcode | 1D Laser / 2D Imager Scan Engine (Optional) |
RFID | 13.56 MHz RFID supports ISO 14443A/B (Optional) |
Indicator & Buttons | |
LED Indicator | Power/ Wi-fi/Bluetooth/HDD/ 3.75G Status LED |
Keys | 5-way navigation key 8 x programmable function keys |
I/O Interface | |
USB | 2 x USB 2.0 1 x Mini USB Client |
LAN | 1 x 10/100/1000 Mbps GbE RJ-45 |
Audio | 2 x 1.5W Speaker 1 x Mic in |
Power | |
Power Adapter | 12V @ 5A @60 W |
Battery | 7.4 V 2400 mAh Li-ion Battery (Optional 5000mAh) |
Environment | |
Operating Temperature | 0°C to +40°C |
Storage Temperature | -20°C to +60°C |
Humidity | 5%~95% non-condensing |
Drop Survival | 1.0 M |
Environmental Protection | Front Panel IP62 compliant |
Certification | CE/FCC |
Physical Characteristics | |
Dimensions (LxWxH) (mm) | 255 x 180 x 37 |
Weight | 1170 g |
